Inventory # 44783 Year: 2008
HMT 50TSR 3-Axis CNC Tube Bender
Specifications
- Max. Pipe O.D. (S = 56,893.4 PSI): 2" x 0.12"
- Max. Pipe O.D. (For Repeat Feeding): 2"
- Round Tube - Non-Ferrous (S = 35,558.4 PSI): 2" x 0.2"
- Round Tube - Stainless (S = 85,340.1 PSI): 2" x 0.07"
- Square Tube - Mild Steel (S = 56,893.4 PSI): 1.57" x 0.12"
- Round Bar - Mild Steel (S = 56,893.4 PSI): 0.98"
- Max. Bending Radius: 1.18" - 8.66"
- Max. Bending Radius - Square Tube: 1.18" - 7.48"
- Max. Bending Angle: 190°
- Max. Length Over Mandrel: 86.61"
- Working Height: 43.3"
- Tooling Center Line Height: 1.57"
- D.O.B. Speed: 80° per second
- Accuracy of D.O.B.: +/- 0.1°
- D.B.B. Speed: 51.18 IPS
- Accuracy of D.B.B.: +/- 0.004"
- P.O.B. Speed: 270° per second
- Accuracy of P.O.B.: +/- 0.1°
- Motor For Hydraulic: 10.2 hp
- Total Power: 12.9 hp
- Max. Pressure: 1991.27 PSI
- Default Pressure: 1422.33 PSI
- Hydraulic Tank Capacity: 47.55 Gallons
- Show More
- Show Less
- Max. Pipe O.D. (S = 3999.61 kgs./sq.cm. ): 50.80mm x 3.05mm
- Max. Pipe O.D. (For Repeat Feeding): 50.80mm
- Round Tube - Non-Ferrous (S = 2499.76 kgs./sq.cm. ): 50.80mm x 5.08mm
- Round Tube - Stainless (S = 5999.41 kgs./sq.cm. ): 50.80mm x 1.78mm
- Square Tube - Mild Steel (S = 3999.61 kgs./sq.cm. ): 39.88mm x 3.05mm
- Round Bar - Mild Steel (S = 3999.61 kgs./sq.cm. ): 24.89mm
- Max. Bending Radius: 29.97mm - 219.96mm
- Max. Bending Radius - Square Tube: 29.97mm - 189.99mm
- Max. Bending Angle: 190°
- Max. Length Over Mandrel: 2199.89mm
- Working Height: 1099.82mm
- Tooling Center Line Height: 39.88mm
- D.O.B. Speed: 80° per second
- Accuracy of D.O.B.: +/- 0.1°
- D.B.B. Speed: 1299.97 mm/sec
- Accuracy of D.B.B.: +/- 0.10mm
- P.O.B. Speed: 270° per second
- Accuracy of P.O.B.: +/- 0.1°
- Motor For Hydraulic: 7.61 kw
- Total Power: 9.62 kw
- Max. Pressure: 139.99 kgs./sq.cm.
- Default Pressure: 99.99 kgs./sq.cm.
- Hydraulic Tank Capacity: 180 liters
- Show More
- Show Less
Location & Terms
- Terms: As Is, Where Is
- Disclaimer: Preliminary Specifications....
