Inventory # 46697 Year: 2021 New - Never Used

Hydratight 2250P Boring BAR System

Send a text message to yourself or a friend

Note: On submit, this will open your devices SMS application

Message will say:

Perfection Global Equipment: https://perfectionglobal.com/blog/the-top-8-cnc-machine-tool-makes-for-manufacturers/?ProductNumber=46697

Inventory # 46697 Year: 2021 New - Never Used
https://perfectionglobal.com/blog/the-top-8-cnc-machine-tool-makes-for-manufacturers/?ProductNumber=46697

Hydratight 2250P Boring BAR System

Request a Quote
Measurement

Specifications
  • Bar Diameter: 2.25"
  • Bar Length (Min.): 48"
  • Bar Length (Max.): 144"
  • Tool Spacing: 6"
  • Cutting Tool: 0.5"
  • Axial Stroke: 12"
  • Feed Rate: 0 - 0.019"/Revolution
  • MACHINING RANGE
  • Boring Heads 2.25" Bar:
  • - Bar Mount: 2.5" - 5.0"
  • - Small: 4.5" - 8.0"
  • - Medium: 6.38" - 12.5"
  • - Large: 10.0" - 24.0"
  • Boring Heads 1.75" Bar:
  • - Bar Mount: 2.0" - 4.5"
  • - Boring Head: 4.5" - 10.0"
  • Boring Heads 1.25" Bar:
  • - Bar Mount: 1.5" - 4.0"
  • - Boring Head: 4.0" - 8.5"
  • Facing/Grooving: 2.5" - 21.0"
  • Swing Diameter: 19.1"
  • Feed Rate: 0.0.24"/Revolution
  • Show More
  • Show Less
  • Bar Diameter: 57.15mm
  • Bar Length (Min.): 1219.20mm
  • Bar Length (Max.): 3657.60mm
  • Tool Spacing: 152.40mm
  • Cutting Tool: 12.70mm
  • Axial Stroke: 304.80mm
  • Feed Rate: 0 - 0.483mm /Revolution
  • MACHINING RANGE
  • Boring Heads 57.15mm Bar:
  • - Bar Mount: 63.50mm - 127.00mm
  • - Small: 114.30mm - 203.20mm
  • - Medium: 162.05mm - 317.50mm
  • - Large: 254.00mm - 609.60mm
  • Boring Heads 44.45mm Bar:
  • - Bar Mount: 50.80mm - 114.30mm
  • - Boring Head: 114.30mm - 254.00mm
  • Boring Heads 31.75mm Bar:
  • - Bar Mount: 38.10mm - 101.60mm
  • - Boring Head: 101.60mm - 215.90mm
  • Facing/Grooving: 63.50mm - 533.40mm
  • Swing Diameter: 485.14mm
  • Feed Rate: 0.0.24"/Revolution
  • Show More
  • Show Less
Location & Terms
  • Terms: As Is, Where Is
  • Disclaimer: Preliminary Specifications....
