Specifications
- Pressing Force: 180 Ton
- Stroke Length: 5.9"
- Stroke Speed Range: 70 - 200 SPM
- Shut Height Adjustment: 3.9"
- Shut Height on Bed (SDAU): 20.6"
- Bed Area (L-R x F-B): 74.8" x 33.5"
- Upright Opening: 24.8"
- Slide Area (L-R x F-B): 74.8" x 33.5"
- Motor Power: 75 HP
- Show More
- Show Less
- Pressing Force: 1,600 kN
- Stroke Length: 150mm
- Stroke Speed Range: 70 - 200 SPM
- Shut Height Adjustment: 100mm
- Shut Height on Bed (SDAU): 525mm
- Bed Area (L-R x F-B): 1900mm x 850mm
- Upright Opening: 630mm
- Slide Area (L-R x F-B): 1900mm x 850mm
- Motor Power: 56 kw
- Show More
- Show Less
Equipped With
- Willet Transfer System
- Four Piece High Tensile Cast Iron Frame
- Mounting Pads/Machining on Uprights & Front of Bed
- Bed Deflection
- Auxiliary Flywheel
- Air Operated Flywheel Brake
- Large Hydrostatic Piston Drive
- Slide Guiding System
- Show More
- Show Less
- Willet Transfer System
- Four Piece High Tensile Cast Iron Frame
- Mounting Pads/Machining on Uprights & Front of Bed
- Bed Deflection
- Auxiliary Flywheel
- Air Operated Flywheel Brake
- Large Hydrostatic Piston Drive
- Slide Guiding System
- Show More
- Show Less
Location & Terms
- Terms: As Is, Where Is
- Disclaimer: Preliminary Specifications....
