Inventory # 46760 Year: 2011
** ITEM IS SOLD - if you are looking for a similar item OR have a similar item to sell please contact us Phone 847-427-3333 or email scott@perfectionglobal.com Trumpf TruLaser Tube 7000 3600W CNC Tube Laser
Specifications
- Laser Power: 3600 Watts
- X-Axis Travel: 362.2"
- Y-Axis Travel: 12.6"
- Z-Axis Travel: 9"
- Tube Diameter Capacity: 9.84"
- Max. Raw Material Length: 362.2"
- Min. Raw Material Length: 98.4"
- Max. Length of Finished Parts: 118"
- Min. Remaining Tube Length: 4.7"
- Max. Material Thickness: 0.3"
- Max. Bundle Cross-Section: 23.6" x 23.6"
- Max. Bundle Weight: 8800 lbs.
- Max. Tool Weight (Raw Material): 330 lbs.
- Max. Tool Weight (Finished Part): 55 lbs.
- X-Axis Travel Speed: 3,937 IPM
- Y-Axis Travel Speed: 2362 IPM
- Z-Axis Travel Speed: 2362 IPM
- Positioning Accuracy Pa: .008"
- Avg. Position Range Ps: .0023"
- Smallest Programmable Increment: .0004"
- Focal Length of Cutting Head w/ Lens: 6.1"
- Trumpf TruFlow 3600 Resonator
- Max. Laser Wattage (Programmable in 1% Increments): 3600W
- Max. Mild Steel Thickness: 0.31"
- Max. Stainless Steel Thickness: 0.24"
- Max. Aluminum Thickness: 0.2"
- Show More
- Show Less
- Laser Power: 3600 Watts
- X-Axis Travel: 9199.88mm
- Y-Axis Travel: 320.04mm
- Z-Axis Travel: 228.60mm
- Tube Diameter Capacity: 249.94mm
- Max. Raw Material Length: 9199.88mm
- Min. Raw Material Length: 2499.36mm
- Max. Length of Finished Parts: 2997.20mm
- Min. Remaining Tube Length: 119.38mm
- Max. Material Thickness: 7.62mm
- Max. Bundle Cross-Section: 599.44mm x 599.44mm
- Max. Bundle Weight: 3990.80 kg.
- Max. Tool Weight (Raw Material): 149.66 kg.
- Max. Tool Weight (Finished Part): 24.94 kg.
- X-Axis Travel Speed: 3,396.66 mm/sec
- Y-Axis Travel Speed: 59.99 m/min
- Z-Axis Travel Speed: 59.99 m/min
- Positioning Accuracy Pa: 0.20mm
- Avg. Position Range Ps: 0.06mm
- Smallest Programmable Increment: 0.01mm
- Focal Length of Cutting Head w/ Lens: 154.94mm
- Trumpf TruFlow 3600 Resonator
- Max. Laser Wattage (Programmable in 1% Increments): 3600W
- Max. Mild Steel Thickness: 7.87mm
- Max. Stainless Steel Thickness: 6.10mm
- Max. Aluminum Thickness: 5.08mm
- Show More
- Show Less
Equipped With
- Siemens Sinumerik 840D sl CNC Control
- Trumpf TruFlow 3600 Resonator
- Additional Spare Cutting Head
- Scrap Conveyor
- Dust Collection Unit
- Unload Station
- 9 Meter Loadmaster Bundle Loader w/ Conveyor - Single Piece Load Option
- Show More
- Show Less
- Siemens Sinumerik 840D sl CNC Control
- Trumpf TruFlow 3600 Resonator
- Additional Spare Cutting Head
- Scrap Conveyor
- Dust Collection Unit
- Unload Station
- 9 Meter Loadmaster Bundle Loader w/ Conveyor - Single Piece Load Option
- Show More
- Show Less
Location & Terms
- Terms: As Is, Where Is
- Disclaimer: Preliminary Specifications....
