Specifications
- Wattage: 6 kw (1 kw - 10 kw Options Available)
- Capacity (Mild Steel): .984 Ga
- X-Axis Travel: 120"
- Y-Axis Travel: 60"
- Z-Axis Travel: 4.7"
- Axis Speeds: 5,900 IPM
- Synchronized Speeds: 8,270 IPM
- Pallet Size: (2) 60" x 120"
- Load Capacity: 3,300 lb.
- Positioning Accuracy: 0.002"
- Repeatability: 0.001"
- Pallet Change Speed: 24 Seconds
- Show More
- Show Less
- Wattage: 6 kw (1 kw - 10 kw Options Available)
- Capacity (Mild Steel): .984 Ga
- X-Axis Travel: 3048.00mm
- Y-Axis Travel: 1524.00mm
- Z-Axis Travel: 119.38mm
- Axis Speeds: 5,381.00 mm/sec
- Synchronized Speeds: 8,114.30 mm/sec
- Pallet Size: (2) 1524.00mm x 3048.00mm
- Load Capacity: 1,500 kg
- Positioning Accuracy: 0.05mm
- Repeatability: 0.03mm
- Pallet Change Speed: 24 Seconds
- Show More
- Show Less
Equipped With
- ESA S675W 21” CNC Touch Screen Control
- IPG 6 kw Laser Source
- Precitec ProCutter 2 Auto Focus Laser Head
- Lantek Automatic Nesting Software
- Lantek Expert Cut CAD CAM
- INA Linear Guide Ways
- Precitec Lasermatic Height Controller
- Dust Collector
- IPG Laser Chiller Unit
- Schneider Electrical Components
- Show More
- Show Less
- ESA S675W 533.40mm CNC Touch Screen Control
- IPG 6 kw Laser Source
- Precitec ProCutter 2 Auto Focus Laser Head
- Lantek Automatic Nesting Software
- Lantek Expert Cut CAD CAM
- INA Linear Guide Ways
- Precitec Lasermatic Height Controller
- Dust Collector
- IPG Laser Chiller Unit
- Schneider Electrical Components
- Show More
- Show Less
Location & Terms
- Terms: F.O.B.
- Disclaimer: Preliminary Specifications....
