Inventory # 47428 Year: 2021
Doosan LYNX 2100LSYB CNC Turning Center
Specifications
- Chuck: 8"
- Bar Capacity: 2.6"
- Max. Turning Diameter: 12"
- Max. Turning Length: 20"
- Through Hole Diameter: 2.6"
- Max. Spindle Speed: 4500 RPM
- Max. Spindle Power: 20 hp
- Max. Spindle Torque: 125 ft-lbs
- Boring Bar Diameter: 1.3"
- Number of Tools: 12
- Tool Speed: 6000 RPM
- Shank: BMT-45
- X-Axis Travel: 8"
- Y-Axis Travel: 4"
- Z-Axis Travel: 22"
- X-Axis Rapid Traverse: 1181 ipm
- Z-Axis Rapid Traverse: 1417 ipm
- Show More
- Show Less
- Chuck: 203.20 mm
- Bar Capacity: 66.04mm
- Max. Turning Diameter: 300 mm
- Max. Turning Length: 510 mm
- Through Hole Diameter: 66 mm
- Max. Spindle Speed: 4500 RPM
- Max. Spindle Power: 15 kw
- Max. Spindle Torque: 169 N·m
- Boring Bar Diameter: 32 mm
- Number of Tools: 12
- Tool Speed: 6000 RPM
- Shank: BMT-45
- X-Axis Travel: 205 mm
- Y-Axis Travel: 105 mm
- Z-Axis Travel: 560 mm
- X-Axis Rapid Traverse: 30 m/min
- Z-Axis Rapid Traverse: 36 m/min
- Show More
- Show Less
Equipped With
- FANUC CNC Control
- LNS Alpha SL65-S Servo Bar Feed
- LNS Chip Conveyor
- Mist Collector
- Transformer
- Accessories
- Show More
- Show Less
- FANUC CNC Control
- LNS Alpha SL65-S Servo Bar Feed
- LNS Chip Conveyor
- Mist Collector
- Transformer
- Accessories
- Show More
- Show Less
Location & Terms
- Terms: F.O.B.
- Location: Elk Grove Village, IL
- Disclaimer: Preliminary Specifications....
